| MODEL : BS |
 |
| BELT DRIVEN TYPE SPINDLES |
| -.FOOT MOUNT or SLEEVE TYPE ( MAX 60,000RPM ) |
|
|
|
Model |
Max RPM |
Height |
Lub |
Housing DIA' |
Shaft dia' |
Quill dia' |
Quill screw |
| 1 |
BS 060 |
60,000 |
76.2MM(3")
MOUNT TYPE |
Oil
Grease(option) |
71 |
20 |
12 |
M10 |
| 2 |
BS 050 |
50,000 |
77 |
25 |
16 |
M14 |
| 3 |
BS 040 |
40,000 |
80 |
30 |
18 |
M16 |
| 4 |
BS 030 |
30,000 |
97 |
40 |
22 |
M20 |
| 5 |
BS 024 |
24,000 |
108 |
50 |
28 |
M24 |
| 6 |
BS 018 |
18,000 |
125 |
65 |
36 |
M30 |
|
|
Belt driven type spindles |
|
